Wall Mounted Home Energy Storage Battery
- Brand Name: Dali
- Model Number: LFS25.6-100、LFS25.6-200、LFS51.2-100、LFS51.2-200、LFS51.2-280
- Capacity: 100Ah--280Ah
- Voltage: 25.6V、51.2V
- DC output:
- Battery Type: LiFePO4
- Inverter Type:
Description
Efficient Energy Storage: High energy density lithium-ion batteries support fast charging and discharging. They are compatible with photovoltaic systems, maximizing the utilization of solar energy and reducing reliance on the grid.
Intelligent Energy Management: Equipped with built-in AI algorithms, it automatically switches between charging and discharging modes (peak and valley pricing/emergency power supply/solar priority). The mobile app allows for remote monitoring, providing real-time insights into battery levels, power consumption, and profit data.
Safety and Reliability: Featuring fire and explosion-resistant design, it has an IP65 protection rating, making it suitable for complex environments such as humid and high-temperature conditions. It includes multi-layer protection mechanisms (overcharge, over-discharge, short-circuit, and temperature anomalies).
Compact Wall-Mounted Design: With an ultra-thin profile, it saves space and seamlessly blends into home environments. It operates silently with no mechanical noise.
Specifications
| Model | LFS25.6-100 | LFS25.6-200 | LFS51.2-100 | LFS51.2-200 | LFS51.2-280 |
| Rated voltage | 25.6V | 25.6V | 51.2V | 51.2V | 51.2V |
| Rated capacity | 100AH | 200AH | 100AH | 200AH | 280AH |
| Discharge current | 100A | 150A | 100A | 200A | 200A |
| Peak discharge current | 300A | 300A | 300A | 300A | 300A |
| Cut-off discharge voltage | 22.4V | 22.4V | 44.8V | 44.8V | 44.8V |
| Charging voltage | 29.2V | 29.2V | 58.4V | 58.4V | 58.4V |
| Charging current | 20A | 40A | 20A | 40A | 56A |
| Weight (kg) | 24 | 46.5 | 46.5 | 83 | 115 |
| Dimensions (Length × Width × Height) mm | 370*160*400 | 370*160*600 | 370*160*60 | 500*170*850 | 852*588*260 |
